High Flow / Low Pressure Drop Polyester Felt Filter Bags – All Standard & Custom Sizes Available
High Flow / Low Pressure Drop Polyester Felt Filter Bags – All Standard & Custom Sizes Available
High Flow / Low Pressure Drop Polyester Felt Filter Bags – All Standard & Custom Sizes Available High Flow / Low Pressure Drop Polyester Felt Filter Bags – All Standard & Custom Sizes Available High Flow / Low Pressure Drop Polyester Felt Filter Bags – All Standard & Custom Sizes Available High Flow / Low Pressure Drop Polyester Felt Filter Bags – All Standard & Custom Sizes Available High Flow / Low Pressure Drop Polyester Felt Filter Bags – All Standard & Custom Sizes Available
接触

High Flow / Low Pressure Drop Polyester Felt Filter Bags – All Standard & Custom Sizes Available

最小注文数量 : 200個 価格 : $1 for 200 pcs, $0.9 for 10,000 pcs, $0.7 for 50, 000 pcs
パッケージの詳細 : PEバッグに袋を折り 50-1000PCSをカートンに 受渡し時間 : 5営業日
支払条件 : L/C、T/T、ペイパル 供給の能力 : 1, 0000 pcs / 日
起源の場所: 浙江省、中国 ブランド名: SHARE FILTERS
証明: Reach Svhc, SGS RoHS, California Proposition 65 モデル番号: SG-PES-2

詳細情報
材料: ポリエステルフェルト 形: 方形またはV/U形
マイクロン評価: 0.2um～300um コラーリング: プラスチック製のフレンズ,引糸,または亜鉛製の鋼輪
シーム: 縫い 溶接 バッグのサイズ: 1 #2 #3 #4 #5 およびカスタムサイズ
アプリケーション: 液体と固体分離,粉末除去,燃料ガス処理 パッケージ: PE袋に袋を折ります。50～100個/パックをカートンに入れます。
HSコード: 56029000
ハイライト:

high flow polyester felt filter bags

,

low pressure drop mesh filter bags

,

custom size polyester filter bags

製品の説明

Highlights at a glance

Available ratings: 0.2, 0.5, 1, 3, 5, 10, 25, 50, 75, 100, 125, 200, 300 μm

Available felt material: polyester, polypropylene, PTFE, PPS

All industry standard & custom sizes

Broad chemical compatibility

High flow/low pressure drop

Sewn or fully-welded construction

Handles on all bags

Different ring/flange styles available

Temperature ratings to 180°F(PP), 275°

F (PES) and 500°F (PTFE)

















































Material Micron Rating Size Seam Top Bottom

 Felt in

 polypropylene(PP)

 polyester(PE)

 PTFE

 PPS



 Mesh in

 nylon(NMO)

 polyeseter

 polypropylene

 0.2um to 2500um

 depending on fabrics

 1# 180*410mm
 2# 180*810mm
 3# 102*210mm
 4# 102*360mm
 5# 152*560mm

 custom sizes

 Stitched,

 Welded

 Plastic ring

 Metal ring

 Raw top

 Drawstring

 "Arc" shape

 "V" shape

 "U" shape









SHARE FELT filter bags are mainly made of polyester, polypropylene, PTFE or PPS by non-woven needle felt and textile technology. It has good air permeability, smooth surface, good dimensional stability, easy to peel off dust and other excellent performance. It is mainly used in liquid and solid separation, dust removal and normal temperature fuel gas treatment in industries.

Our polyester and polypropylene needle felt filter media are treated to prevent fiber migration downstream. These standard felts are versatile for various industrial processes, silicone-free for automotive and paint applications. Additionally, our polyester and polypropylene felts comply with FDA and EU regulations for food contact applications.







High Flow / Low Pressure Drop Polyester Felt Filter Bags – All Standard & Custom Sizes Available 0High Flow / Low Pressure Drop Polyester Felt Filter Bags – All Standard & Custom Sizes Available 1High Flow / Low Pressure Drop Polyester Felt Filter Bags – All Standard & Custom Sizes Available 2High Flow / Low Pressure Drop Polyester Felt Filter Bags – All Standard & Custom Sizes Available 3High Flow / Low Pressure Drop Polyester Felt Filter Bags – All Standard & Custom Sizes Available 4High Flow / Low Pressure Drop Polyester Felt Filter Bags – All Standard & Custom Sizes Available 5High Flow / Low Pressure Drop Polyester Felt Filter Bags – All Standard & Custom Sizes Available 6High Flow / Low Pressure Drop Polyester Felt Filter Bags – All Standard & Custom Sizes Available 7High Flow / Low Pressure Drop Polyester Felt Filter Bags – All Standard & Custom Sizes Available 8High Flow / Low Pressure Drop Polyester Felt Filter Bags – All Standard & Custom Sizes Available 9High Flow / Low Pressure Drop Polyester Felt Filter Bags – All Standard & Custom Sizes Available 10High Flow / Low Pressure Drop Polyester Felt Filter Bags – All Standard & Custom Sizes Available 11High Flow / Low Pressure Drop Polyester Felt Filter Bags – All Standard & Custom Sizes Available 12High Flow / Low Pressure Drop Polyester Felt Filter Bags – All Standard & Custom Sizes Available 13High Flow / Low Pressure Drop Polyester Felt Filter Bags – All Standard & Custom Sizes Available 14High Flow / Low Pressure Drop Polyester Felt Filter Bags – All Standard & Custom Sizes Available 15High Flow / Low Pressure Drop Polyester Felt Filter Bags – All Standard & Custom Sizes Available 16High Flow / Low Pressure Drop Polyester Felt Filter Bags – All Standard & Custom Sizes Available 17High Flow / Low Pressure Drop Polyester Felt Filter Bags – All Standard & Custom Sizes Available 18High Flow / Low Pressure Drop Polyester Felt Filter Bags – All Standard & Custom Sizes Available 19High Flow / Low Pressure Drop Polyester Felt Filter Bags – All Standard & Custom Sizes Available 20High Flow / Low Pressure Drop Polyester Felt Filter Bags – All Standard & Custom Sizes Available 21High Flow / Low Pressure Drop Polyester Felt Filter Bags – All Standard & Custom Sizes Available 22
High Flow / Low Pressure Drop Polyester Felt Filter Bags – All Standard & Custom Sizes Available 23



Liquid filter felt bag are often used in

  • Electric paint coating line filtration.
  • Pre-discharge treatment, circuit board production cycle water filtration.
  • Automobile production coating line, metal casting, pre-ultrafiltration protection filtration, spray water filtration and oil filtration.
  • Solid-liquid separation in petrochemical, light industrial food, metallurgy, electronics, pharmaceutical, etc.
  • Handling pre-cleaning, electrophoretic paint, spray rinse water, circulating water, etc. in the automotive industry.
  • Solvent purification treatment, resin treatment and wastewater treatment in the paint industry.

High Flow / Low Pressure Drop Polyester Felt Filter Bags – All Standard & Custom Sizes Available 24



Related Products





SHARE provides a wide range of liquid filter bags with plastic collar or stainless steel ring or drawstring. Micron rataings range from 0.2 micron to 2500 micron.



Our liquid filter bags provide excellent strength, consistent openings and has no fiber migration.

Our filter bags are available in many different sizes & shapes and can be customised.

Contact SHARE for further information.




Packaging & Shipping

Filter bags are packed into sealed PE bags. The label contains the following standard information:

item name, manufacturer, material, dimensions, manufacturing date, order number, batch number etc.



  Port to Port Door to Door
Express(DHL,UPS,FEDEX, EMS)   1 - 5 days
Air Freight 1 - 5 days 4 - 10 days
Sea Freight(FCL) 15 - 30 days 20 - 35 days
Sea Freight(LCL) 15 - 30 days 22 - 37 days





Company Profile



High Flow / Low Pressure Drop Polyester Felt Filter Bags – All Standard & Custom Sizes Available 25







FAQ



1. Where is your factory located? How can I visit there?

We are in Taizhou city, Zhejiang province China. By train, we are one hour away from Hangzhou and two hours away from Shanghai.

2. Can I get free samples and how long can you deliver them?
We are pleased to provide you with free samples for your evaluation, which will be sent to you within 2 days. Please feel free to reach out to us for samples.

3. How long does a quotation take?
In most cases, we respond within 2 days. If something in RFQ need be confirmed, we will promptly notify you soon.

4. How quickly can I get my order finished?
The production lead time is dependent on the quantity. Typically, it takes 5 to 15 working days for us to complete mass production once you have placed the order.

5. What about your quality control?
By visual inspection, optical or pressure sensitive equipment and automated 3D image-inspection equipment, our production operators conduct self-inspections at every stage of the process. Additionally, we have spot inspections and final inspections carried out by our Quality Control (QC) team.

6. What's your largest advantage?
One of our core competencies is our excellent converting capabilities from yarn over weaving to converted items with professional technical team and quality guarantee and management for more than 30 years.

7. What kind of payment terms do you accept?
T/T and LC and more.
